Si-tex
Sitex SAS-900 Class A AIS SAS-900
- SKU:
- SITSAS900
- UPC:
- 010407421063
- MPN:
- SAS-900
- Condition:
- New
Description
Sitex SAS-900 Class A AIS
Model: SAS-900- Internationally certifed SOLAS, MED, FCC, Inland Waterway, Industry Canada
- IPx6 & IPx7 water and weather proof
- Inter-operable with all other bridge system
- High performance detailed Electronic Charts - C-Map
- Multi-lingual, intuitive user interface
- MOB & SART alert and tracking
- Integrated WiFi
- NMEA0183 & 2000
SAS-900 is the world’s most sophisticated and robust SOLAS and Inland-Waterway certified AIS Class A Transceiver.
Fourth generation AIS technology delivers unmatched real world AIS receive, transmit and message processing performance and reliability. Quality engineered and manufactured without compromise, with features such as IPx7 weather proofing and integrated shock & vibration protection for continuous long term operation in even the harshest commercial or military environment.
A large integrated high definition color screen maximizes the benefit of the SAS-900’s powerful Electronic Chart display engine with full detailed chart AIS overlay, and multiple target management functionality, including innovative MOB features and many more.
Specifications| Dimensions | 152mm x 165mm x 111mm |
| Weight | 1.5kg |
| Electrical | |
| Power supply | 12 to 24VDC |
| Power consumption | < 12W |
| Connectors | |
| VHF antenna connector | SO-239 / UHF |
| GNSS antenna connector | TNC |
| Power | Two pin connector (cable provided) |
| Serial interfaces and alarm relay | 18 pin connector (cable provided) |
| Serial inputs | 14 pin connector (cable provided) |
| NMEA2000® | NMEA 2000 Micro connector |
| Data Interfaces | |
| NMEA0183 (IEC61162-2) bi-directional ports | 3 |
| NMEA0183 (IEC61162-1) sensor inputs | 3 |
| DGPS correction data input (ITUR M.823-2) | 1 |
| Alarm relay output | 1 |
| NMEA2000 | 1 |
| WiFi | 802.11 b/g/n |
| Pilot port | 1 (optional) |
| VHF Transceiver | |
| Transmitter | 1 |
| Receiver | 3 |
| Frequency | 156.025MHZ to 162.025MHz |
| Output power | 1W or 12.5W (automatic) |
| Channel bandwidth | 25kHz |
| Channel step | 25kHz |
| Modulation modes | GMSK-TDMA |
| Bit rate | 9600bits/sec |
| Receiver sensitivity | -107dBm @ 20% PER |
| GNSS Receiver and Antenna | |
| Channels | 72 |
| GNSS systems | Support parallel dual mode operation from GPS and GLONASS |
| IEC61108-1 Complian | Compliant |
| GNSS antenna | Supplied |
What's in the Box:
- SAS900
- Mounting bracket
- GOS Antenna with cable
- 18 way data cable
- 14 way data cable
- Power cable
- Mounting hardware
- Documentation
